KTJ1-150 Cam Controller

About the KTJ1-150 Cam Controller

The KTJ1-150 Cam Controller is part of the ELEHPD Cam Switch range. 1、KTJ1-150 series cam controller,is used in 50HZ voltage to 380 V circuits, mainly used as starting, speed governing and inverting the AC motor. 2、Type meaning: ： The cam controller of Model KTJ1-150/1 is used as controlling the winding the line type reaction motor of a set of three phases. ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.

Typical applications

Motor control centres and pump or fan starters
Machine building, conveyors, packaging and CNC equipment
HVAC control panels and building automation
Water treatment, irrigation and pumping stations
Panel retrofits replacing electromechanical control gear

How to specify the right Cam Switch

Size the contact rating for the inductive load, not just the resistive current (AC-3 duty for motors)
Check the coil voltage and frequency available in the panel: 24 V DC, 110 V, 230 V or 400 V AC
Confirm the auxiliary contact count needed for the control and indication circuit
Match the enclosure rating to the environment (IP20 inside a panel, IP65 on the machine)

Specifications

KTJ1-150 series AC cam controller

The use and type meaning
1、KTJ1-150 series cam controller,is used in 50HZ voltage to 380 V circuits , mainly used as starting, speed governing and inverting the AC motor.
2、Type meaning: ：

The cam controller of Model KTJ1-150/1 is used as controlling the winding the line type reaction motor of a set of three phases.

Technical data

Type

Specified electric current (A)

Specified voltage (V)

Weight (kilogram)

Forward (Up)

Backward (Down)

inter>The job position counting

Setting up an electric circuit rate =40% motor 380V of high-power (kilowatt ) the mosts controlled

Touch the irregular electric current of a horizontal tablet of head auxiliarily (A)

Operate the number of times the most largly per hour

The biggest work period (minute)
KTJ1-150/1

150

380

7

7

100

15

600

10

85

The appearance and size of installation
Wiring diagram

Note: 1), In moving more systems of driving, other controllers touch head " 1 " and " 2 " while receiving thiscircuit. 2), In the system of urging of many motors, terminal point switch and other controllers touch " 3 " heads , " 4 " , " 5 " while receiving this electricity inside. Cam controller of Model KTJ1-150/1

Frequently asked questions about the KTJ1-150 Cam Controller

What is the difference between a contactor and a relay?

A contactor is built for switching power circuits repeatedly at high current, often with motor duty ratings (AC-3) and arc-suppressing chambers. A relay switches control signals at low current. In practice: contactor for the motor, relay in the control circuit that drives the contactor coil.

How do I calculate the correct contactor size for a motor?

Use the motor's full-load current, apply the AC-3 rating for the operating voltage, and allow for the number of starts per hour. As a rule of thumb, the contactor's AC-3 rating should be at least equal to the motor FLC, then step up one frame if the duty is heavy.

Do you supply the coil voltage I need?

Coil voltages are specified per order. Send the model number, coil voltage and frequency you require and we will confirm availability and lead time.

Are auxiliary contacts included?

Base models come with the standard auxiliary contact configuration for that frame. Add-on auxiliary blocks and mechanical interlocks can be quoted with the contactor.
