Flat Wall Switch

About the Flat Wall Switch

The Flat Wall Switch is part of the ELEHPD Wall Switch range. Flat Wall Switch from the ELEHPD Wall Switch range. ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.

Typical applications

Motor control centres and pump or fan starters
Machine building, conveyors, packaging and CNC equipment
HVAC control panels and building automation
Water treatment, irrigation and pumping stations
Panel retrofits replacing electromechanical control gear

How to specify the right Wall Switch

Size the contact rating for the inductive load, not just the resistive current (AC-3 duty for motors)
Check the coil voltage and frequency available in the panel: 24 V DC, 110 V, 230 V or 400 V AC
Confirm the auxiliary contact count needed for the control and indication circuit
Match the enclosure rating to the environment (IP20 inside a panel, IP65 on the machine)

Specifications

Flat model Wall Switches

EU-SF501 Single Switch EU-SF502 Socket Outlet EU-SF503 Two Way Switch

EU-SF504 Cut Out Switch EU-SF505 Bell Switch EU-SF506 TV Antenna Outlet

EU-SF507 Socket Outlet with cover EU-SF508 Phone Socket Outlet EU-SF509 Dimmer Switch

EU-SF510 Indicator One Way Switch EU-SF511 Indicator Two Way Switch EU-SF512 Schuko Socket Outlet

EU-SF513 One Way Switch EU-SF514 Two Way Switch EU-SF515 Phone Socket Outlet

EU-SF516 Bell Switch EU-SF517 TV Socket Outlet EU-SF518 Schuko Socket Swith
