About the TT-1000 High-Pressure Sodium Lamp
The TT-1000 High-Pressure Sodium Lamp is part of the ELEHPD Sodium Lamp range. Characteristic:High in luminous efficiency,less in power consumption,long in service life,white-golden in ray of light and strong in fogpenetrating capacity.colour temperature 2K. Application:Suitable for lighting in the places of road,airport,whart,station,factory and mine etc. ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.
Typical applications
- Commercial interiors: offices, retail, showrooms and hospitality
- Industrial high-bay lighting for warehouses and workshops
- Outdoor area, street and roadway lighting
- Warehouse, logistics and cold-store facilities
- Project lighting specified through M&E contractors
How to specify the right Sodium Lamp
- Work from the required lux level at the task plane, then the mounting height
- Match beam angle to the space: narrow for high ceilings, wide for low uniform coverage
- Check the IP and IK rating for the installation environment
- Confirm colour temperature and CRI with the interior designer or specifier
Specifications
| High-Pressure Sodium Lamp |
|
Characteristic:High in luminous efficiency,less in power consumption,long in service life,white-golden in ray of light and strong in fogpenetrating capacity.colour temperature 2K.
Application:Suitable for lighting in the places of road,airport,whart,station,factory and mine etc. |
|
Type |
Wattage(w) |
Supply Voltage(v) |
Operating Current(a) |
Luminous Flux(Im) |
Average Life(h) |
Base |
Max Diameter
(mm) |
Max Length
(mm) |
Case qty |
Carton Meas
(cm) |
G/N Weight
(KGS) |
|
SON-TT1000 |
1000 |
110±10 |
10.3 |
130000 |
24000 |
E40/E39 |
67 |
380 |
20 |
38×31×41.5 |
8.0/5.0 | |
|
Type |
Wattage(w) |
Supply Voltage(v) |
Operating Current(a) |
Luminous Flux(Im) |
Average Life(h) |
Base |
Max Diameter
(mm) |
Max Length
(mm) |
Case qty |
Carton Meas
(cm) |
G/N Weight(KGS) |
|
LU-TT1000 |
1000 |
250±10 |
4.70 |
130000 |
24000 |
E40/E39 |
67 |
380 |
20 |
38×31×41.5 |
8.0/5.0 | |
Frequently asked questions about the TT-1000 High-Pressure Sodium Lamp
What colour temperature should I specify?
4000 K neutral white is the safe general choice for industrial and commercial interiors. 3000 K suits hospitality and retail where a warmer look is wanted. 5000-6500 K is common for outdoor and roadway lighting.
What IP rating do I need for outdoor use?
IP65 is the practical minimum for exposed outdoor fixtures. For wash-down or coastal locations, specify IP66 with a corrosion-resistant housing and confirm the IK impact rating.
Can the fixtures be dimmed or sensor-controlled?
Dimming and sensor variants depend on the driver fitted to the model. Tell us the control protocol you use (0-10 V, DALI, triac) and we will confirm compatible models.
Do you supply photometric data for lighting design?
IES/LDT photometric files can be supplied for project models so your designer can run the lighting calculation in DIALux or Relux.
