SON-T High-pressure Sodium Lamp of igniting

About the SON-T High-pressure Sodium Lamp of igniting

The SON-T High-pressure Sodium Lamp of igniting is part of the ELEHPD Sodium Lamp range. SON-T High-pressure Sodium Lamp of igniting from the ELEHPD Sodium Lamp range. ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.

Typical applications

Commercial interiors: offices, retail, showrooms and hospitality
Industrial high-bay lighting for warehouses and workshops
Outdoor area, street and roadway lighting
Warehouse, logistics and cold-store facilities
Project lighting specified through M&E contractors

How to specify the right Sodium Lamp

Work from the required lux level at the task plane, then the mounting height
Match beam angle to the space: narrow for high ceilings, wide for low uniform coverage
Check the IP and IK rating for the installation environment
Confirm colour temperature and CRI with the interior designer or specifier

Specifications

High-pressure sodium lamp of igniting

Type	Wattage(W)	Supply Voltage(V)	Operating Current(A)	Luminous Flux(Im)	Average Life(h)	Base	Max Diameter (mm)	Max Length (mm)	Case qty	Carton Meas(cm)	G/N Weight(KGS)
SON-T70	70	90±10	0.98	3900	6000	E27/E26	38	156	40	35×22.5×21	4.0/2.0
SON-T110	110	90±10	1.20	5600	6000	E27/E26	38	180	40	35×22.5×24	4.0/2.0
SON-T150	150	100±10	1.80	98000	8000	E27/E26	38	211	40	35×22.5×26.5	8.0/5.5
SON-T250	250	100±10	3.00	16900	8000	E40/E39	48	257	40	43×28×29.5	8.5/6.0
SON-T400	400	100±10	4.60	30500	8000	E40/E39	48	283	40	43×28×32	9.5/7.0

Type	Wattage(W)	Supply Voltage(V)	Operating Current(A)	Luminous Flux(Im)	Average Life(h)	Base	Max Diameter (mm)	Max Length (mm)	Case qty	Carton Meas(cm)	G/N Weight(KGS)
SON-T70	70	90±10	0.98	3900	6000	E27/E26	56	141	40	31×25.5×32	4.0/2.1
SON-T110	110	90±10	1.20	5600	6000	E27/E26	56	141	40	31×25.5×32	4.0/2.0
SON-T150	150	100±10	1.80	98000	8000	E27/E26	91	225	20	48.5×39×25	6.0/3.0
SON-T250	250	100±10	3.50	16900	8000	E40/E39	91	225	20	48.5×39×25	6.0/3.0
SON-T400	400	100±10	4.60	30500	8000	E40/E39	120	290	15	63.5×38.5×30.5	7.0/3.5

High-pressure sodium lamp of igniting (coated)

Characteristic:High in luminous efficiency,less in power consumption,long in service life,white-golden in ray of light and strong in fogpenetrating capacity.colour temperature 2K.
Application:Suitable for lighting in the places of road,airport,whart,station,factory and mine etc.

Type	Wattage(W)	Supply Voltage(V)	Operating Current(A)	Luminous Flux(Im)	Average Life(h)	Base	Max Diameter (mm)	Max Length (mm)	Case qty	Carton Meas(cm)	G/N Weight(KGS)
SON-ED70	70	90±10	0.98	3900	6000	E27/E26	56	141	40	32×25.5×32	4.0/2.1
SON-ED110	110	90±10	1.20	5100	6000	E27/E26	56	141	40	31×25.5×32	4.0/2.0
SON-ED210	210	100±10	2.15	13000	8000	E40/E39	91	225	20	48.5×39×25	6.0/3.0
SON-ED36	360	100±10	3.40	26000	8000	E40/E39	120	290	15	63.5×38.5×30.5	7.0/3.5

Frequently asked questions about the SON-T High-pressure Sodium Lamp of igniting

What colour temperature should I specify?

4000 K neutral white is the safe general choice for industrial and commercial interiors. 3000 K suits hospitality and retail where a warmer look is wanted. 5000-6500 K is common for outdoor and roadway lighting.

What IP rating do I need for outdoor use?

IP65 is the practical minimum for exposed outdoor fixtures. For wash-down or coastal locations, specify IP66 with a corrosion-resistant housing and confirm the IK impact rating.

Can the fixtures be dimmed or sensor-controlled?

Dimming and sensor variants depend on the driver fitted to the model. Tell us the control protocol you use (0-10 V, DALI, triac) and we will confirm compatible models.

Do you supply photometric data for lighting design?

IES/LDT photometric files can be supplied for project models so your designer can run the lighting calculation in DIALux or Relux.
