About the SD-96 DC V

The SD-96 DC V is part of the ELEHPD Panel Meter range. Name 96 Moving Coil instrument DC Voltmeter Model > Voltmeter > 96 Series Type SD-96 DC V Accuracy: class 1.5 Specification: 50mV 60mV 75mV 100mV 3V 5V 7.5V 10V 15V 20V 30V 50V 75V 100V 120V 150V 200V 250V 300V 400V 450V 500V 600V, measuring ranges over 600V with external resistor (rated current 5mA) ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.

Typical applications

Motor control centres and pump or fan starters
Machine building, conveyors, packaging and CNC equipment
HVAC control panels and building automation
Water treatment, irrigation and pumping stations
Panel retrofits replacing electromechanical control gear

How to specify the right Panel Meter

Size the contact rating for the inductive load, not just the resistive current (AC-3 duty for motors)
Check the coil voltage and frequency available in the panel: 24 V DC, 110 V, 230 V or 400 V AC
Confirm the auxiliary contact count needed for the control and indication circuit
Match the enclosure rating to the environment (IP20 inside a panel, IP65 on the machine)

Specifications

	Name	96 Moving Coil instrument DC Voltmeter
Model	> Voltmeter > 96 Series
Type	SD-96 DC V
Accuracy: class 1.5 Specification: 50mV 60mV 75mV 100mV 3V 5V 7.5V 10V 15V 20V 30V 50V 75V 100V 120V 150V 200V 250V 300V 400V 450V 500V 600V, measuring ranges over 600V with external resistor (rated current 5mA)
