SD-96 DC A

About the SD-96 DC A

The SD-96 DC A is part of the ELEHPD Panel Meter range. Name 96 Moving Coil instrument DC Ammeter Model > Ammeter > 96 Series Type SD-96 DC A Accuracy: class 1.5 Specification: 50uA 100uA 150uA 500uA 1mA 2mA 5mA 10mA 20mA 30mA 50mA 75mA 100mA 150mA 200mA 250mA 300mA 500mA 1A 2A 3A 7.5A 10A 20A 30A 50A 60A, if measuring ranges over 60A, meters can be connected external shunt with 50mV,60mV or 75mV ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.

Typical applications

Motor control centres and pump or fan starters
Machine building, conveyors, packaging and CNC equipment
HVAC control panels and building automation
Water treatment, irrigation and pumping stations
Panel retrofits replacing electromechanical control gear

How to specify the right Panel Meter

Size the contact rating for the inductive load, not just the resistive current (AC-3 duty for motors)
Check the coil voltage and frequency available in the panel: 24 V DC, 110 V, 230 V or 400 V AC
Confirm the auxiliary contact count needed for the control and indication circuit
Match the enclosure rating to the environment (IP20 inside a panel, IP65 on the machine)

Specifications

	Name	96 Moving Coil instrument DC Ammeter
Model	> Ammeter > 96 Series
Type	SD-96 DC A
Accuracy: class 1.5 Specification: 50uA 100uA 150uA 500uA 1mA 2mA 5mA 10mA 20mA 30mA 50mA 75mA 100mA 150mA 200mA 250mA 300mA 500mA 1A 2A 3A 7.5A 10A 20A 30A 50A 60A, if measuring ranges over 60A, meters can be connected external shunt with 50mV,60mV or 75mV
