About the Metal Halide Lamp 2269
The Metal Halide Lamp 2269 is part of the ELEHPD Metal Halide Lamp range. Type Wattage (w) Operating Current(a) Luminous Flux(Im) Color Tem- perature (k) Average Life(h) Base Max Diameter (mm) Max Length (mm) Burning Position Case qty Carton Meas(cm) G/N Weight (KGS) JLZ-TO400N 400 4.0 36000 5000 8000 E40/E39 67 283 Horizontal±45 25 34.5×34.5×34.5 6.0/4.5 JLZ-TO400D 400 4.0 36000 6400 8000 E40/E39 67 283 Horizontal±45 25 34.5×34.5×34.5 6.0/4.5   ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.
Typical applications
- Commercial interiors: offices, retail, showrooms and hospitality
- Industrial high-bay lighting for warehouses and workshops
- Outdoor area, street and roadway lighting
- Warehouse, logistics and cold-store facilities
- Project lighting specified through M&E contractors
How to specify the right Metal Halide Lamp
- Work from the required lux level at the task plane, then the mounting height
- Match beam angle to the space: narrow for high ceilings, wide for low uniform coverage
- Check the IP and IK rating for the installation environment
- Confirm colour temperature and CRI with the interior designer or specifier
Specifications
|
Type |
Wattage
(w) |
Operating Current(a) |
Luminous Flux(Im) |
Color Tem-
perature (k) |
Average Life(h) |
Base |
Max Diameter
(mm) |
Max Length
(mm) |
Burning Position |
Case qty |
Carton Meas(cm) |
G/N Weight
(KGS) |
|
JLZ-TO400N |
400 |
4.0 |
36000 |
5000 |
8000 |
E40/E39 |
67 |
283 |
Horizontal±45 |
25 |
34.5×34.5×34.5 |
6.0/4.5 |
|
JLZ-TO400D |
400 |
4.0 |
36000 |
6400 |
8000 |
E40/E39 |
67 |
283 |
|
25 |
34.5×34.5×34.5 |
6.0/4.5 | |
|
Type |
Wattage
(w) |
Operating Current
(a) |
Luminous Flux(Im) |
Color Temp-
erature(k) |
Average Life
(h) |
Base |
Max Diameter
(mm) |
Max Length
(mm) |
Burning Position |
Case qty |
Carton Meas(cm) |
G/N Weight
(KGS) |
|
JLZ-T250N |
250 |
3.0 |
20500 |
5000 |
8000 |
E40/E39 |
48 |
257 |
Horizontal±45 |
40 |
43×28×29.5 |
8.5/6.0 |
|
JLZ-T250D |
250 |
3.0 |
16000 |
6400 |
6000 |
E40/E39 |
48 |
257 |
|
40 |
43×28×30 |
8.5/6.0 |
|
JLZ-T400D |
400 |
4.0 |
36000 |
5000 |
10000 |
E40/E39 |
48 |
283 |
|
40 |
43×28×30 |
9.5/7.0 | |
|
Type |
Wattage
(w) |
Operating Current
(a) |
Luminous Flux(Im) |
Color Temp-
erature(k) |
Average Life(h) |
Base |
Max Diameter
(mm) |
Max Length
(mm) |
Burning Position |
Case qty |
Carton Meas(cm) |
G/N Weight
(KGS) |
|
JLZ-T250N |
250 |
2.15 |
16000 |
6400 |
5000 |
E40/E39 |
48 |
257 |
Horizontal±45 |
40 |
43×28×30 |
8.5/6.0 |
|
JLZ-T400D |
400 |
3.40 |
26000 |
6400 |
5000 |
E40/E39 |
48 |
283 |
|
40 |
43×28×33 |
9.5/5.5 | |
Frequently asked questions about the Metal Halide Lamp 2269
What colour temperature should I specify?
4000 K neutral white is the safe general choice for industrial and commercial interiors. 3000 K suits hospitality and retail where a warmer look is wanted. 5000-6500 K is common for outdoor and roadway lighting.
What IP rating do I need for outdoor use?
IP65 is the practical minimum for exposed outdoor fixtures. For wash-down or coastal locations, specify IP66 with a corrosion-resistant housing and confirm the IK impact rating.
Can the fixtures be dimmed or sensor-controlled?
Dimming and sensor variants depend on the driver fitted to the model. Tell us the control protocol you use (0-10 V, DALI, triac) and we will confirm compatible models.
Do you supply photometric data for lighting design?
IES/LDT photometric files can be supplied for project models so your designer can run the lighting calculation in DIALux or Relux.
