Color Bulb

About the Color Bulb

The Color Bulb is part of the ELEHPD Incandescent Bulb range. NO. Type Voltage Power Base Colour Size ER1037 C7 5V - 260V 3W - 25W E14/E17 Clear,Red,Green,Blue,Yellow,White 30x75mm ER1038 C9 5V - 260V 3W - 15W E12/E12S/E14/E14S Clear,Red,Green,Blue,Yellow,White 23x54mm ELEHPD manufactures and exports low voltage electrical products from Yueqing, Zhejiang, China, supplying distributors, panel builders, M&E contractors and OEM buyers worldwide.

Typical applications

Commercial interiors: offices, retail, showrooms and hospitality
Industrial high-bay lighting for warehouses and workshops
Outdoor area, street and roadway lighting
Warehouse, logistics and cold-store facilities
Project lighting specified through M&E contractors

How to specify the right Incandescent Bulb

Work from the required lux level at the task plane, then the mounting height
Match beam angle to the space: narrow for high ceilings, wide for low uniform coverage
Check the IP and IK rating for the installation environment
Confirm colour temperature and CRI with the interior designer or specifier

Specifications


Number：ER-1032	Item No.：ER-1033


Number：ER-1034	Item No.：ER-1037


Number：ER-1035	Item No.：ER-1036


Number：ER-1031	Item No.：ER-1038

Color Incandescent Bulb

NO.	Type	Voltage	Power	Base	Colour	Size
ER1031	A19	5V - 260V	5W - 60W	B22/E27	Clear,Red,Green,Blue,Yellow,White	60x102mm
ER1032	G45	5V - 260V	5W - 25W	B22/E27/E14S	Clear,Red,Green,Blue,Yellow,White	45x70mm
ER1033	G40	5V - 260V	5W - 25W	B22/E27/E14S	Clear,Red,Green,Blue,Yellow,White	40x60mm
ER1034	C35	5V - 260V	5W - 25W	B22/E27/E14S	Clear,Red,Green,Blue,Yellow,White	35x100mm
ER1035	C32	5V - 260V	5W - 25W	B22/E27/E14S	Clear,Red,Green,Blue,Yellow,White	232x95mm
ER1036	D30	5V - 260V	5W - 25W	B22/E27	Clear,Red,Green,Blue,Yellow,White	30x62mm

NO.	Type	Voltage	Power	Base	Colour	Size
ER1037	C7	5V - 260V	3W - 25W	E14/E17	Clear,Red,Green,Blue,Yellow,White	30x75mm
ER1038	C9	5V - 260V	3W - 15W	E12/E12S/E14/E14S	Clear,Red,Green,Blue,Yellow,White	23x54mm

Frequently asked questions about the Color Bulb

What colour temperature should I specify?

4000 K neutral white is the safe general choice for industrial and commercial interiors. 3000 K suits hospitality and retail where a warmer look is wanted. 5000-6500 K is common for outdoor and roadway lighting.

What IP rating do I need for outdoor use?

IP65 is the practical minimum for exposed outdoor fixtures. For wash-down or coastal locations, specify IP66 with a corrosion-resistant housing and confirm the IK impact rating.

Can the fixtures be dimmed or sensor-controlled?

Dimming and sensor variants depend on the driver fitted to the model. Tell us the control protocol you use (0-10 V, DALI, triac) and we will confirm compatible models.

Do you supply photometric data for lighting design?

IES/LDT photometric files can be supplied for project models so your designer can run the lighting calculation in DIALux or Relux.
